Areas of application

• General illumination
• Hospitality
• Offices
• Retail
• Wall washing

Product features

• Energy saving replacement for fluorescent FT40DL/25W & FT40DL/28W lamps
• Installed directly on 120-277V; no ballast required
• CCT: 3000K
• Lifetime (L70): up to 50,000 h
• Suitable for open and enclosed fixtures
• No warm-up time, instant-on with full light output and stable lamp-to-lamp color
• For use with shunted and non-shunted sockets, therefore no socket change is needed
• Maximize energy savings with occupancy sensors
• 2G11 four pin base
• Optimized glass optical design to mimic traditional fluorescent TT5 lamp
• 5-year limited lamp warranty (24/7 operation)
• Mercury-free and RoHS compliant

Safety advice

• Double ended platform where lamp is wired end-to-end preventing nonpassive failure of a fluorescent lamp should it be inadvertently installed in the fixture.
• All installation, inspection, and maintenance of lighting fixtures should be done with the power to the fixture turned off.
• Lamps should be installed and operated in compliance with the National Electrical Code (NEC), Underwriters Laboratories Inc. (UL) requirements, and all applicable codes and regulations.
• Ensure lamp holders/sockets are in good operating condition before installation.
• Not for emergency lighting.
• Not to be used with dimmers.
• Do not use LEDlescent DULUX L LED TT5 lamps with external LED drivers or ballasts.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
• Please read and comply with all instructions before attempting inspection, service or installation.
• Suitable for dry and damp locations (cannot come in direct contact with water).
